Product Description
Smooth and Precise Power Transmission
The AF90 Helical Gear Reducer is designed for controlled rotary motion.
Its helical gear profile improves tooth engagement during power transmission.
This design helps reduce mechanical shock during continuous operation.
AF90 delivers smooth torque transfer for demanding automation systems.
The AF90 Precision Helical Gear Reducer suits precision transmission applications.
Built for Servo and Automation Equipment
AF90 offers multiple reduction ratios for different motion requirements.
Its nominal input speed reaches 3,000 rpm.
The maximum input speed reaches 6,000 rpm for high-speed servo applications.
Its maximum radial load reaches 2,400 N.
The AF90 Helical Gear Reducer for Servo Motor supports frequent machine cycles.
It also suits robotics, CNC equipment, and industrial automation machinery.
Controlled Backlash and Mechanical Performance
AF90 is available with precision and standard backlash options.
The precision version can achieve backlash as low as 3 arcmin.
Low backlash helps improve positioning repeatability and motion response.
Rated output torque ranges from 50 to 96 N·m.
Maximum axial load reaches 2,200 N.
These characteristics support demanding mechanical transmission applications.
Precision Manufacturing and Assembly
Critical gears and transmission components undergo precision machining.
Gear accuracy directly affects operating stability and transmission quality.
Assembly controls gear engagement, axial clearance, and bearing fit.
Each unit undergoes operational and transmission performance checks before shipment.
This process helps maintain consistent performance between production batches.
The AF90 Low Backlash Precision Gear Reducer suits demanding motion systems.
Reliable Performance for Industrial Environments
AF90 uses synthetic grease for long-term transmission lubrication.
Its IP65 protection rating supports operation in demanding industrial environments.
Operating noise is approximately 62 dB under specified conditions.
The average service life reaches 20,000 hours.
AF90 suits packaging machines, assembly equipment, and automated production lines.
The AF90 Helical Gear Reducer Manufacturer can support different configuration requirements.
AF90 Product Specifications
- Model: AF90 Helical Gear Reducer
- Gearbox Type: Precision helical gear reducer
- Available Ratios: 3, 4, 5, 7, 10, 15, 16, 20, 25, 28, 30, 35, 40, 50, 70, and 100
- Transmission Stages: Single-stage or two-stage
- Rated Output Torque: 44–96 N·m, depending on the selected ratio
- Nominal Input Speed: 3,000 rpm
- Maximum Input Speed: 6,000 rpm
- Maximum Radial Load: 2,400 N
- Maximum Axial Load: 2,200 N
- Emergency Stop Torque: 3 times the rated output torque
- Efficiency: 97% for single-stage; 95% for two-stage operation
- Average Service Life: 20,000 hours
- Moment of Inertia: 0.39–0.72 kg·cm² across the listed ratios
- Backlash: Precision ≤3 arcmin; standard ≤5 arcmin or ≤7 arcmin
- Torsional Rigidity: 14 N·m/arcmin
- Operating Noise: 62 dB
- Lubrication: Synthetic grease
- Protection Rating: IP65
- Weight: Approximately 3.7 kg for single-stage; 4.2 kg for two-stage
- Typical Applications: Servo motors, motion-control systems, and industrial automation equipment
- Mechanical Dimensions: The supplied specification table does not include AF90 dimensional drawings. Flange size, mounting holes, shaft dimensions, and overall length should follow the dedicated AF90 mechanical drawing.
