ZPLE160 High Precision Reducer Product Description
Built for High-Precision Heavy-Duty Transmission
The ZPLE160 High Precision Reducer is engineered for large industrial equipment.
Its reinforced planetary transmission structure increases overall rigidity.
Optimized gear engagement minimizes transmission errors.
As a ZPLE160 High Precision Reducer Manufacturer, we deliver dependable industrial power transmission solutions.
The reducer performs reliably under continuous heavy-duty operation.
Stable output maintains exceptional motion accuracy.
The robust construction extends equipment service life.
Precision Manufacturing for Reliable Performance
Critical gears are produced from premium alloy steel.
Every gear receives precision hobbing and grinding processes.
Advanced heat treatment improves wear resistance and fatigue strength.
Strict inspection guarantees consistent product quality.
As a ZPLE160 Precision Planetary Reducer Supplier, we follow rigorous manufacturing standards.
High-quality bearings reduce friction and improve efficiency.
The sealed lubrication system minimizes maintenance requirements.
Optimized for Demanding Motion Control Applications
The ZPLE160 integrates seamlessly with advanced servo systems.
Low backlash improves repeatable positioning accuracy.
High rigidity supports rapid acceleration and deceleration.
Efficient transmission reduces overall energy consumption.
As a ZPLE160 Low Backlash Precision Reducer for Servo Motor, it is widely used in robotics, CNC machines, automated production lines, laser processing equipment, and intelligent logistics systems.
Smooth operation minimizes vibration and operating noise.
Accurate torque delivery increases production efficiency.
Flexible Integration Across Multiple Industries
The ZPLE160 offers various reduction ratio options.
Standard mounting dimensions simplify equipment integration.
Customized input flanges and output shafts are available.
Application engineers assist with optimal product selection.
The reducer is suitable for new energy equipment, aerospace manufacturing, semiconductor machinery, and precision inspection systems.
Its reliable construction supports continuous industrial operation.
The ZPLE160 provides efficient, accurate, and dependable transmission for next-generation automation equipment.
ZPLE160 High Precision Reducer Specifications
General Information
- Model: ZPLE160
- Product Name: ZPLE160 High Precision Reducer
- Product Category: High-precision planetary reducer / Precision servo gearbox
- Series: ZPLE Inline Precision Planetary Reducer Series
- Frame Size: 160 mm standard frame
- Transmission Type: Multi-stage precision planetary gear system
- Mounting Style: Standard flange mounting compatible with various servo motors
- Output Design: High-rigidity solid output shaft
Mechanical Construction
- Gear Material: Case-hardened high-strength alloy steel
- Housing Material: High-rigidity aluminum alloy or optional ductile iron
- Gear Manufacturing: CNC gear hobbing, precision grinding, and matched assembly
- Heat Treatment: Vacuum carburizing, hardening, and precision tempering
- Bearing Arrangement: Heavy-duty high-precision angular contact bearings
- Lubrication: Lifetime sealed synthetic grease
- Sealing System: Multi-layer dustproof and oil-retaining seal structure
- Connection Design: High-concentricity flange interface
Performance Specifications
- Reduction Ratios: 3:1, 4:1, 5:1, 7:1, 10:1, plus two-stage and three-stage combinations
- Backlash: Precision low-backlash configuration for demanding positioning tasks
- Rated Output Torque: Designed for continuous heavy-load operation
- Peak Torque Capacity: Suitable for short-duration overload conditions
- Transmission Efficiency: Up to 97% in single-stage configurations
- Input Speed: Compatible with high-speed servo drive systems
- Noise Level: Optimized tooth geometry for quiet operation
- Repeatability: Stable positioning performance in precision motion applications
- Service Life: Engineered for continuous industrial production
Applications and Options
- Typical Equipment: Six-axis robots, gantry robots, heavy-duty manipulators, CNC machining centers, laser cutting systems, semiconductor equipment, and lithium battery automation lines
- Compatible Motors: AC servo motors, permanent magnet synchronous motors, and high-performance stepper motors
- Key Features: High rigidity, high precision, high torque, low backlash, and extended durability
- Customization: Multiple input flanges, output shaft styles, gear ratios, and special mounting dimensions
- Inspection Procedures: Backlash measurement, torque verification, noise inspection, temperature rise testing, endurance testing, and complete operational validation
- Supply Service: OEM, ODM, bulk production, and worldwide export support.
